Studer Innotec SA
RCC-02/-03
User manual V4.4.0 9
3
INTRODUCTION
Congratulations! The purchase of an RCC remote control offers you unlimited access to the various
functions of the devices in the Xtender series. Numerous configurations that can now be accessed
allow you to optimize the operation of the installation. Despite all these options, the Xtender works
on a simple basis.
Different figure scenarios as well as associated configurations are presented at the end of this
manual.
The manual for the RCC remote control is divided into several distinct parts:
The first part (page 11 to 26) is dedicated to the adjustments of the RCC remote control, whether this
is the language used or the clock, which are sometimes necessary for the whole installation to work
well.
The second part (page 27 to 34) is concerned with immediate information on the installation. This
gives access to the electric values such as the battery voltage, inverter load and many more.
The third part (page 35 to 35) shows the functions for saving events occurring in the installation. This
may be necessary for diagnosing a weakness or simply to check that the whole unit is working well
during its whole service life.
The fourth part (page 36 to 74), which is more technical, presents various options for configuring the
Xtender.
Do not change the configurations except when you have the technical knowledge; otherwise, the
operation of the installation could at risk or installation itself could be partly damaged.
The fifth part (page 76 to 79) consists of more general items like information about the system, the
updating process or examples of applications.
The sixth part (page 81 to 94) consists of two tables with all "Remote control" and "Inverter"
parameters. These tables, which follow the same hierarchical order as in the remote control, give an
overview on all adjustable parameters and also information about the factory settings.
3.1 MODELS CONCERNED
The RCC remote control may be connected to any Xtender, VarioTrack or VarioString the use of
which is clearly detailed in its operating instructions.
3.2 CONTROLS AND INDICATORS
The RCC remote control is equipped with four operating keys as well as a graphic display
with back-lighting. The function of the keys may change according to the context of
utilisation and a reminder of the function in progress is given at the right of the display.
Generally the keys UP and DOWN are used to alter values or options relating to what is on
the display and the two central keys are used to access, confirm or quit the item shown.
If the back-lighting function is activated, pressing one of the keys starts it up.
