Studer Innotec SA
RCC-02/-03
30 V4.4.0 User manual
12
MESSAGES AND ACCOUNT OF EVENTS
This screen allows you to view the various events that
have occurred in the installation.
The events that occur in your installation are displayed on the remote control screen. The events are
classified within two categories:
The events that may have serious consequences are displayed up to the moment where the
user confirms that he has taken note of them by pressing on an RCC remote control key.
These events are recorded in the event history and may be consulted subsequently.
Events not posing a risk are indicated briefly on the display and then disappear. Some are
recorded in the event history.
There are four different types of messages:
Notification: general information on the funtionning of the installation.
Warning: an event that may cause the system to malfunction or to shut down if not taken care of.
Error: a function of the system has been deactivated.
Halted: The system had to be stopped as a major event is preventing its operation.
Notifications are indicated by their reference number whereas the other messages include both
message type and reference number.
Caution, a stop can be temporary and the system can restart automatically. In case
of work on the installation, switch off the system.
INSTALLER - In the message history, you may clear the list of saved messages. The clear function is
signalled by ‘CLR’, opposite the SET button. You must confirm to clear the list of messages.
Use this function, for example, after maintenance visit or when completing the
commissioning of the installation.
12.1 (000) WARNING: BATTERY VOLTAGE LOW
The battery is almost completely discharged. If the situation persists, the inverter function of the
Xtender will be deactivated.
Solution:
recharge your battery as soon as possible
recharge your battery more frequently
increase the power or the energy available for the load (for instance with more solar panels)
This message is generated in conjunction with the undervoltage of the battery
configuration {1108}.
The service life of the batteries is greatly conditioned by their state of charge.
Prolonged or repeated operation at a low charge may cause damage.
With the Smart-Boost function activated, it is also possible to discharge the batteries
even if connected to a source of energy.
12.2 (003) AC-IN SYNCHRONIZATION IN PROGRESS
A valid voltage has been detected on the AC-In input and the Xtender is synchronizing. Once
synchronized, the consumers will be transferred to it and the battery will be charged.
Note: It is possible to prohibit the transfer or the battery charging.
