EN/07.2013/58/81
CONDENSER PRESSURE HIGH STATUS 49
OUTPUT POWER LIMIT STATUS 50
EEV IN FAILURE 51
AMBIENT TEMPERATURE INVALID 52
SUCTION PRESSURE INVALID 53
CONDENSER PRESSURE INVALID 54
PERIPHERALS ERROR 55
OUT OF ENVELOPE 56
OVER CURRENT 57
OVER VOLTAGE 58
DRIVE TEMPERATURE HIGH 59
SUPPLY VOLTAGE LOW 60
DISCHARGE TEMPERATURE HIGH 61
DISCHARGE TEMPERATURE INVALID 62
INTERNAL ERROR 63
PLC COMMUNICATION ERROR 64
HOURS OF OPERATING OF FANS 65
RUNTIME ERROR 66
THERMOSTAT HIGH TEMP 67
CONDENSER PRESSURE 68
ALARM ACTIVE 69
FAN 1 ERROR 70
FAN 2 ERROR 71
FAN 3 ERROR 72
FC STOP BY WIND 73
FC STOP BY FIRE 74
Read input registers (0x04)
With this function it’s possible to read the value of the input/output analog channels.
The value is sent by two bytes, the first one is the MSB.
All the values are multiplied by 10. To get the real value it is necessary dividing by 10. For example, if the value of the
parameter at address 1 is 115, the real value will be 11.5.
ModBus function 0x04: read input registers ModBus address
Analog Inputs
Internal relative humidity (IRH) 1
Pressure of condenser (PC) 2
External relative humidity (ERH) 3
Temperature of evaporator (TE) 4
Temperature of condenser (TC) 5
Internal temperature (TI) 6
External temperature (TAE) 7
Delivery air temperature (TM) 8
Delivery air temperature of comfort unit 1 (TM1) - Custom 13 9
Delivery air temperature of comfort unit 2 (TM2) - Custom 13 10
Internal temperature 1 (TI1) - Custom 9 11
Internal temperature 2 (TI2) - Custom 9 12
Analog Outputs
