Electronic Control System
3-16
#3758407 - Revision B - August, 2006
UNIQUE ELECTRONIC CONTROL INPUT OPERATIONS
The following pages illustrate unique input operations performed at the control panel that you would not expect a
customer to perform every day. The input operations described are: Temperature Unit Selection Mode, Sabbath
Mode, Showroom Mode, Manual Compartment Disable Mode and Manual Freezer Evaporator Defrost.
Temperature Units Selection Mode (Selecting Degrees Fahrenheit or Degrees Celsius Display)
The electronic control is initially set to display temperature in Fahrenheit (°F) units of measure. Units of measure
can be converted from °F to °C (Celsius), and/or back again. This operation is called Temperature Units Selection.
NOTE: Temperature Units Selection must be performed within the first minute after switching the unit ON.
To convert temperature units of measure from Fahrenheit (°F) to Celsius (°C) readings, press and hold the door ajar
alarm bell ON/OFF key and the UNIT ON/OFF key simultaneously for 5 seconds, then release the keys (See Figure
3-21). “ °C “ will appear on the LCD indicating that temperatures will now be displayed in Celsius units of measure.
To convert back to Fahrenheit units of measure, repeat the steps above (See Figure 3-22).
NOTE: Temperature Units Selection Mode will end 10 seconds after the last key stroke.
NOTE: Do not
press and hold the UNIT ON/OFF key first, that will simply switch the unit OFF.
Figure 3-21. Converting Temperature Units of Measure to °C (within first minute after switching unit ON) -
Press and Hold Bell ON/OFF Key and UNIT ON/OFF Key for 5 Seconds
Press and hold for 5 seconds
Figure 3-22. Converting Temperature Units of Measure to °F (within first minute after switching unit ON) -
Press and Hold Bell ON/OFF Key and UNIT ON/OFF Key for 5 Seconds
Press and hold for 5 seconds
