Sub-Zero 632-2 User Manual

Built-In
Built-In
(600-
(600-
2
2
)
)
Series
Series
Wiring Diagrams / Schematics
PART NUMBER 3756690
FREEZER
FAN SWITCH
FREEZER
LIGHT SWITCH
DEFROST
TERMINATOR
LIGHT
TERMINATOR
FREEZER
OVERLOAD
PROTECTOR
ICEMAKER
SWITCH
NEUT
115 VOLTS
60 CYCLES
L1
FILL TUBE
HEATER
FREEZER
LIGHTS
DRAIN TROUGH
HEATER
DRAIN
HEATER
DEFROST
HEATER
FREEZER
COMPRESSOR
STARTING
RELAY
FREEZER
FAN MOTOR
WATER
VALVE
ICEMAKER
CONDENSER
FAN MOTOR
FREEZER
COMPRESSOR
RUNNING
CAPACITOR
HIGH VOLTAGE WIRING SCHEMATIC
-This wiring information is provided for use by qualified
service personnel only.
-Disconnect appliance from electrical supply before
beginning service.
-Be sure all grounding devices are connected when
service is complete.
-Failure to observe the above warnings may result in
severe electrical shock.
1890 OHMS
260 OHMS
21 OHMS
2600 OHMS
YELLOW
WHITE/BLUE
ORANGE
GRAY/WHITE
BLUE
J3
J2
E10E7E2 E6
J4
J1
J7
J5
WHITE
BLACK
TAN
PINK
PURPLE
J6
WHITE
160 OHMS
RED
M
M
M
A1
WIRING SCHEMATIC
MODEL: 601F-2
10-7
#3758407 - Revision B - August, 2006
