Air Flow & Fan Blade Spacing
Built-In
Built-In
(600-
(600-
2
2
)
)
Series
Series
5-6
#3758407 - Revision B -
August, 2006
Figure 5-9.
Air Flow and Fan Blade Sp
acing, Model 695-2 (Prior to Serial #2269189)
Clamp Down
REFRIGERA
TOR
F
AN BRACKET
TO F
AN
BLADE HUB SP
ACING
Clamp Back
FREEZER
F
AN BRACKET
TO F
AN
BLADE HUB SP
ACING
1-1/4" ± 1/16"
(31.75 mm ± 1.59 mm)
7/8" ± 1/16"
(22.23 mm ± 1.59 mm)
Figure 5-10.
Air Flow/Fan Blade Sp
ace, 685-2 (St
arting w/Serial #2271
174), 695-2 (St
arting w/Serial #2269189)
Clamp Down
REFRIGERA
TOR
F
AN BRACKET
TO F
AN
BLADE HUB SP
ACING
Clamp Back
FREEZER
F
AN BRACKET
TO F
AN
BLADE HUB SP
ACING
1-1/4" ± 1/16"
(31.75 mm ± 1.59 mm)
7/8" ± 1/16"
(22.23 mm ± 1.59 mm)
59
