Appendix
WARNING
• Avoid dropping or jarring your Subgear XP-3H.
• Do not allow your Subgear XP-3H to be exposed to direct, intense
sunlight.
• Rinse your Subgear XP-3H thoroughly with fresh water after each dive.
• Do not store your Subgear XP-3H in a sealed container; make sure
there is free ventilation.
• If there are problems with the water contacts, use soapy water to clean
Subgear XP-3H and dry it thoroughly. The surface of your Subgear
XP-3H housing can be treated with silicone grease. Do not apply
grease to the water contacts!
• Do not clean Subgear XP-3H with liquids containing solvent (apart
from water).
• Check the battery capacity before each dive ->15.
• If the battery icon appears, replace the battery ->76.
• Diving with a weak battery: Subgear XP-3H may stop working during
the dive, service icon and error code "E3" or "E6" appear. Close the
dive and replace the battery ->76.
• On the surface: if service icon and error code "E3" appear, replace the
battery ->76.
All error codes other than E3: Subgear XP-3H must not be used for
any further dives. Take your dive computer to an authorized SUBGEAR
dealer.
8.2.1 Connecting the high pressure hose
Subgear XP-3H may only be used with SUBGEAR high pressure hose.
If you need to remove or reconnect the high pressure connection, two
wrenches must be used as shown in the figure.
When connected directly to a high pressue hose, be sure that the swivel is
inserted with proper size and material O ring.
When quick release system is assembled, the O-ring between the bayonet
and XP-3H replaces the swivel.
Quick release system attached to the Subgear XP-3H is shown at the picture.
Be sure that high pressure is not applied when connecting or disconnecting the
Subgear XP-3H from the quick release.
The bayonet must be fully pushed in when cover is twisted to locking
position. In the correct locking position the bayonet moves forward approx
4mm (1/5 of an inch) and stays securely locked. Apply the high pressure
to the system only after quick release has been correctly closed.
