14.3 Cable and housing routing – Electronic wire routing
1. Insert Di2 front derailleur cable from hole behind seat tube until it exits from
the BB hole.
2. Plug the cable into the junction box.
3. Install the plug grommet (SKU: 80804) in the FD housing exit hole and the Di2
grommet (SKU: 80805) into the Di2 seat tube hole.
80805
80804
