Subsite 910R - Page 51

910R/950R/950T/970T - OPERATION 51
LOCATE LINE: ACTIVE LOCATION
910R/950R/950T/970T - OPERATION 51
LOCATE LINE: ACTIVE LOCATION
Broadcast Induction
To set up transmitter for broadcast induction:
1. Remove cable, stake, clamp and any other metal objects
from transmitter.
2. Place transmitter parallel to and directly above suspected line
as shown.
3. Turn on transmitter.
4. Check battery level.
5. Choose frequency, power level, and shutoff time. See
“Choose Frequency” earlier in this chapter.
Broadcast Induction
To set up transmitter for broadcast induction:
1. Remove cable, stake, clamp and any other metal objects
from transmitter.
2. Place transmitter parallel to and directly above suspected line
as shown.
3. Turn on transmitter.
4. Check battery level.
5. Choose frequency, power level, and shutoff time. See
“Choose Frequency” earlier in this chapter.
