Suburban SW6PR Service Training Manual

RECREATIONAL VEHICLE FORCED AIR FURNACES (ALL MODELS)
DESCRIPTION OF REPLACEMENT PART SET-UP TIME REPLACEMENT TIME
*Replace Gas Valve ....................................................................... .50 .................................................... .50
Replace Main Burner ................................................................... .50 .................................................... .50
Replace Microswitch .................................................................... .50 .................................................... .25
*Replace Motor .............................................................................. .25 .................................................... 1.00
Replace Blower Wheel ................................................................ .50 .................................................... .40
*Replace Combustion Chamber (Two Years Only)........................ .50 .................................................... 1.50
Replace Thermostat ..................................................................... .25 .................................................... .20
Replace Transformer ................................................................... .50 .................................................... .50
Replace Electrode ....................................................................... .25 .................................................... .25
Replace Electrode - ”SF” Models ................................................. .50 .................................................... .50
Replace Electrode Wire ............................................................... .50 .................................................... .20
*Replace Module Board................................................................. .50 .................................................... .25
Replace Limit Switch ................................................................... .50 .................................................... .20
Replace On/Off Switch ................................................................. .50 .................................................... .20
Replace Blower Housing (Plastic) Room Air Rear Half ............... .25 .................................................... .45
Replace Combustion Air Housing (Plastic) Rear Half .................. .25 .................................................... .45
Replace Combustion Air Housing (Plastic) Front Half ................. .25 .................................................... .45
*Parts required to be returned for warranty.
RECREATIONAL VEHICLE COOKING APPLIANCES (ALL MODELS)
SUBURBAN RANGES
*Oven Control (T-stat).................................................................................................................................... 1.00
Pilot Thermocouple ...................................................................................................................................... .50
Burner, Oven ................................................................................................................................................ .50
Manifold Assembly ....................................................................................................................................... .50
*Valve, Burner ................................................................................................................................................ .60
Control Panel ............................................................................................................................................... .25
Hinge, Door .................................................................................................................................................. .50
Regulator ...................................................................................................................................................... .50
Burner, Top ................................................................................................................................................... .25
*Parts required to be returned for warranty.
SUBURBAN SLIDE-IN COOKTOPS
Manifold Assembly ....................................................................................................................................... .50
*Valve, Burner ................................................................................................................................................ .60
Control Panel ............................................................................................................................................... .25
*Regulator...................................................................................................................................................... .50
Burner, Top ................................................................................................................................................... .25
*Parts required to be returned for warranty.
SUBURBAN DROP-IN COOKTOPS
Manifold Assembly ....................................................................................................................................... .50
*Valve, Burner ................................................................................................................................................ .60
*Regulator...................................................................................................................................................... .50
Burner, Top ................................................................................................................................................... .25
*Parts required to be returned for warranty.
27
