Suburban SW6PR Service Training Manual

38
PARTS ILLUSTRATION AND REPLACEMENT PARTS
LISTS FOR MODELS SW6DEL, SW10DEL, SW12DEL, SW16DEL
Item
No. Description Part Number
1 Module Board .......................................................... 520814
3 Cover, Module Board ............................................... 090487
6 Bushing, Snap 1/2” .................................................. 070270
7 Bushing, Strain Relief 5/8” ....................................... 230216
8 D.C. Junction Box Assembly.................................... 090517
10 Back Assembly, Flue Collector ................................ 101682
11 Front, Flue Collector ................................................ 101776
12 Valve, Pressure Relief ..............................................161157
13 Screw #10 x 1/4 ....................................................... 121577
15 Cover, Thermostat/Hi-Limit ...................................... 090562
16 Gasket, Thermostat Cover ....................................... 070987
18 Grommet .................................................................. 070874
20 Bracket, Electrode Mounting.................................... 063187
21 Electrode.................................................................. 232258
24 Cover, Element ........................................................ 090445
25 Gasket, Element Cover............................................ 070988
26 Burner Assembly with orice.................................... 010843
27 Flue Collector Back Assembly Complete ................. 101777
28 Electric Element with Gasket
SW6DEL, SW10DEL ............................................... 520789
Electric Element with Gasket
SW12DEL, SW16DEL ............................................. 520900
29 Anode ...................................................................... 232767
31 Grommet .................................................................. 071246
32 Bushing, Snap 1/2” .................................................. 070270
33 Switch, Electric Element .......................................... 232362
34 Gas Fitting ............................................................... 170374
35 Bracket, Valve Mounting .......................................... 063243
36 Valve, Gas (LP) .........................................................161109
37 Manifold, Outlet........................................................ 171420
Item
No. Description Part Number
38 Screw #10 x 1/4 (4 Required) SW6DEL .................. 121577
39 Screw #8-32 x 3/8 Hex HD. (2 Required) ................ 121958
41 Switch Assembly, 12 V.D.C. T-Stat/Hi-Limit ............. 232282
42 Switch Assembly, 120 V.A.C. T-Stat/Hi Limit ........... 232306
44 Cover, Junction Box ................................................. 090576
45 Grommet, Gas Inlet ................................................. 070989
46 Bushing, Snap 7/8” .................................................. 230218
47 A.C. Junction Box Assembly .................................... 090577
48 Nut, 10-24 Keps (Green) ......................................... 121576
49 Bushing, Snap 7/8” .................................................. 230218
50 Foam Jacket Assembly Complete SW6DEL ............ 520868
Foam Jacket Assembly Complete SW10DEL .......... 520869
Foam Jacket Assembly Complete SW12DEL .......... 520960
Foam Jacket Assembly Complete SW16DEL .......... 520961
(With any order for Foam Jacket, also
order Banding Kit 520772)
51 Switch, Lamp and Plate Assembly........................... 232881
52 Screw 8mm - 4.0 x 1/2 Hex Washer Head
(2 Required) ............................................................. 121943
53 Burner Bracket ......................................................... 063444
55 1/4 Loxit Nut (Manifold to Burner) ............................ 171463
56 1/4 Loxit Nut (Manifold to Valve) .............................. 171463
57 Electrode Wire (Not Shown) SW6DEL, SW10DEL, and
SW12DEL ................................................................ 232456
Electrode Wire (Not Shown) SW16DEL .................. 232459
58 Relay........................................................................ 232948
59 Screw # 10 X 1/4 (2 Required)
SW10DEL/SW12DEL, SW16DEL ........................... 121577
