Suburban SW6PR Service Training Manual

INTRODUCTION
This Service and Training Manual provided by the Suburban Products Factory
Service Department is intended to be used by qualied service technicians
only as a valuable tool in terms of product identication, troubleshooting and
diagnosis of service issues, and as an outline for information concerning
proper procedures for ling warranty service claims.
Included in this manual are product and component identication
descriptions, sequence of operation information, maintenance and service
recommendations, and warranty processing procedures. In addition to the
information available in this manual other resources for servicing Suburban
Products RV appliances include our website at www.RVComfort.com, our
Factory Service Department Support Line at 423-775-2131 EXT. 7102,
and our Customer Service Department Ofce at 423-775-2131 EXT.
7101.
Having an understanding of the appliance’s sequence of operation and
access to or knowledge of the wiring diagram are the cornerstones of
proper diagnosis and troubleshooting. Other points of emphasis include
an understanding of the appliance’s individual component identication
and function, the adherence to proper installation methods which includes
variables such as voltage and gas pressure, along with constant measurable
factors such as the compliance to the physical installation tolerances and
clearances. This manual is designed to assist service technicians in making
the correct diagnosis efciently.
Proper maintenance and service of an appliance is of the upmost importance.
Failure to keep the appliance clean and well maintained is a signicant
contributing factor in the component breakdown and premature failure of
the appliance.
3
SERVICE TOOLS REQUIRED:
Manometer or U-Tube
Multi-Meter
Circuit Board Tester - Part No. 641511
Gas Thermostat Wrench
Various Nut Drivers
Various Open End Wrenches
Adjustable Wrench
Phillips Screwdriver
Leak Test Solution
Needle Nose Pliers
1 1/16” & 1 1/2” Sockets with Ratchet
and Extensions
Safety Glasses

Suburban SW6PR Specifications

General

Brand	Suburban
Model	SW6PR
Category	Water Heater
Language	English
