31
REPLACEMENT PARTS LIST FOR MODELS
SW4D, SW6D, SW6DE
Item PART NUMBER
No. Description SW4D SW6D SW6DE
1 Module Board .............................................................................................................. 520814 520814 520814
3 Cover, Module Board ................................................................................................. 090487 090487 090487
6 Bushing, Snap 1/2”.......................................................................................................---------- 070270 070270
7 Bushing, Strain Relief 5/8” ...........................................................................................230216 230216 230216
8 D.C. Junction Box Assembly .......................................................................................090517 090517 090517
10 Back Assembly, Flue Collector .....................................................................................101682 101682 101682
11 Front, Flue Collector .....................................................................................................101776 101776 101776
12 Valve, Pressure Relief .................................................................................................. 161157 161157 161157
13 Screw #10 x 1/4 ...........................................................................................................121577 121577 121577
15 Cover, Thermostat/Hi-Limit ..........................................................................................090562 090562 090562
16 Gasket, Thermostat Cover .......................................................................................... 070987 070987 070987
18 Grommet ......................................................................................................................070874 070874 070874
20 Bracket, Electrode Mounting ........................................................................................063187 063187 063187
21 Electrode ......................................................................................................................232258 232258 232258
24 Cover, Element.............................................................................................................---------- ---------- 090445
25 Gasket, Element Cover ................................................................................................---------- ---------- 070988
26 Burner Assembly with orice ......................................................................................010844 010843 010843
28 Electric Element with Gasket .......................................................................................---------- ---------- 520789
29 Anode ...........................................................................................................................232767 232767 232767
31 Grommet ......................................................................................................................071246 071246 071246
32 Bushing, Snap 1/2”.......................................................................................................---------- ---------- 070270
33 Switch, Electric Element ...............................................................................................---------- ---------- 232362
34 Gas Fitting .................................................................................................................... 170374 170374 170374
35 Bracket, Valve Mounting ..............................................................................................063243 063243 063243
36 Valve, Gas (LP) ............................................................................................................ 161109 161109 161109
37 Manifold, Outlet ............................................................................................................171420 171420 171420
38 #10 x 1/4 (4 Required) .................................................................................................121577 121577 121577
39 Screw #8-32 x 3/8 Hex HD. (2 Required).....................................................................121958 121958 121958
41 Switch Assembly, 12 V.D.C. T-Stat/Hi-Limit .................................................................232282 232282 232282
42 Switch Assembly, 120 V.A.C. T-Stat/Hi Limit ................................................................---------- ---------- 232306
44 Cover, Junction Box .....................................................................................................---------- ---------- 090576
45 Grommet, Gas Inlet ...................................................................................................... ---------- 070989 070989
46 Bushing, Snap 7/8”.......................................................................................................---------- ---------- 230218
47 A.C. Junction Box Assembly ........................................................................................---------- ---------- 090575
48 Nut, 10-24 Keps (Green) .............................................................................................. 121576 121576 121576
49 Bushing, Snap 7/8”.......................................................................................................---------- ---------- 230218
50 Foam Jacket Assembly Complete ................................................................................520867 520868 520868
51 Switch, Lamp and Plate Assembly ..............................................................................232589 232589 232589
52 Screw 8mm - 4.0 x 1/2 Hex Washer Head (2 Required) ..............................................121943 121943 121943
53 Burner Bracket .............................................................................................................063444 063444 063444
55 1/4 Loxit Nut (Manifold to Burner) ................................................................................171463 171463 171463
56 1/4 Loxit Nut (Manifold to Valve) ................................................................................. 171463 171463 171463
57 Electrode Wire (Not Shown).........................................................................................232456 232456 232456
