Subzero PRO Series - Opening Dimensions (Dual Unit)

subzero.com | 5
Opening Dimensions
DUAL STANDARD | FLUSH INSTALLATION
NOTE: 3
1
/2" (89) finished returns will be visible and should be finished to match cabinetry.
H
OPENING
HEIGHT
D
OPENING
DEPTH
FRONT VIEW
SIDE VIE
W
TOP VIEW
W
OPENING WIDTH
3
/
4
"
(19)
TYPICAL
FRAMED
CABINETRY
W
FILLER
3
1
/2" (89)
FINISHED
RETURN
FRAMELESS
CABINETRY
W
3
/4" (19)
TYPICAL
3
1
/2" (89)
FINISHED
RETURN
DUAL STANDARD OPENING W H D
Two 36" Models 71⁄" (1816) 83⁄" (2127) 24" (610)
For standard installations, the face frame will extend 2" (51)
beyond cabinetry. A dual installation kit is required for this
installation.
DUAL FLUSH OPENING W H D
Two 36" Models 72" (1829) 84⁄" (2137) 26" (660)
For flush installations, the face frame will be flush with sur-
rounding cabinetry. A dual installation kit is required for this
installation.
Site Preparation
