Sullair 1600H - Instrument Panel Group, Functional Description

1600C LP USER MANUAL SECTION 2
34
2.11 INSTRUMENT PANEL GROUP, FUNCTIONAL DESCRIPTION
Refer to Compass Controller Manual, Sullair Part Number 02250167-454
Figure 2-6: Instrument Panel Group
1. HI/LO Switch
2. Diagnostic Service Port
3. Reset Switch
4. Pressure Gauge
5. Temp/Tach/Fuel Gauge
6. Warning Bank
7. START/ON/OFF Switch
