SECTION 3 1600C LP USER MANUAL
47
3.7 ID, TANDEM AXLE
KEY DESCRIPTION
A1: DIMENSIONS ARE IN INCHES
[] DIMENSIONS ARE IN MILLIMETERS.
A2: ALL DOORS REQUIRE 5 FOOT [1524]CLEARANCE.
A3: REFERENCE: A STANDARD 40’ CONTAINER SIZE IS
88” WIDE X 89” TALL X 234” LONG.
A4: REFERENCE: TWO COMPRESSORS CAN FIT IN A 40’
HIGH CUBE CONTAINER.
A5: ENGINE COOLANT DRAIN
A6: ENGINE OIL DRAIN
A7: COMPRESSOR OIL DRAIN
A8: DRAIN PLUG (9)
A9: TIEDOWN (4)
A10: 100% SPILL CONTAINMENT FRAME
A11: LIFTING BAIL
A12: AIR CONTROL DOOR
A13: INSTRUMENT PANEL DOOR (COMPASS)
A14: E-STOP
A15: OVERALL HEIGHT
A16: ENGINE EXHAUST AIR OUT
A17: ENGINE COOLANT PORT ACCESS COVER
A18: ENGINE AIR INTAKE
A19: UNIT AIR INTAKE
A20: 3” NPT STANDARD AIR DISCHARGE
A21: 3” NPT AFTERCOOLED AIR DISCHARGE
A22: WATER CONDENSATE DRAIN (DO NOT PLUG)
