2.10 Piping and instrumentation—engine
Key Description Qty Notes
1 TURBOCHARGER, ENGINE 1
2 COOLER, CHARGE AIR 1
3 MUFFLER, ENGINE 1
4 SENDER, FUEL LEVEL 1
5 RAIN CAP, EXHAUST SYSTEM 1
6 FILTER, FUEL W/ WATER SEPARATOR 1
7 PUMP, FUEL (INTERNAL TO ENGINE) 1
8 PUMP, FUEL HAND OPERATED PRIMING 1
9 FILTER, FUEL 1
10 VENTILATOR, FUEL TANK 1
11 CAP, FUEL TANK FILL 1
12 THERMOSTAT, THERMOCORD(OPTIONAL) 1
13 KIT, ETHER ASSEMBLY 1
14 PUMP, OIL (INTEGRAL TO ENGINE) 1
15 BY-PASS VALVE (INTERNAL TO ENGINE) 1
16 COOLER, OIL (INTERNAL TO ENGINE) 1
17 FILTER, OIL 1
18 PUMP, WATER (INTEGRAL TO ENGINE) 1
19 RADIATOR, ENGINE 1
20 ENGINE THERMO (INTEGRAL TO ENGINE) 1
21 SENSOR, INLET AIR PRESS(TURBO BOOST) 1
22 SWITCH, COOLANT LEVEL 1
23 SENSOR, FUEL PRESSURE 1
24 SENSOR, FUEL TEMPERATURE 1
25 SENSOR, COOLANT TEMPERATURE 1
26 SENSOR, ENGINE OIL PRESSURE 1
27 SENSOR, CAM SPEED TIMING 1
28 SENSOR, CRANK SPEED TIMING 1
29 HEATER, WATER JACKET (OPTIONAL) 1
30 OIL LEVEL (DIPSTICK) 1
31 FILTER, AIR 1
32 TANK, FUEL 1
33 PAN, ENGINE OIL 1
34 GAUGE, FILTER RESTRICTION 1
35 SENSOR, INLET AIR TEMPERATURE 1
36 VALVE, RELIEF (INTEGRAL TO ENGINE) 1
37 VALVE, AIR STOP (OPTIONAL) 1
38 VALVE, BALL 3-WAY (DUAL PORT) 1
39 COUPLING, QUICK CONNECT 1/2" SUPPLY 1
40 COUPLING, QUICK CONNECT 3/8" RETURN 1
Component Description
L1 COOLANT LEVEL
L2 FUEL LEVEL
L3 OIL LEVEL (DIPSTICK)
P5 INLET MANIFOLD AIR PRESSURE
P6 FUEL PRESSURE
P7 OIL PRESSURE
T7 INLET AIR TEMPERATURE
T8 FUEL TEMPERATURE
T9 COOLANT TEMPERATURE
S1 CAM SPEED
S2 CRANK SPEED
Key Description Qty Notes
