3: Specifications 600H, 750, 750H, 750HH, 825, 900, 900H, 1050 T3 CAT User Manual
02250197-981 R01
40 Subject to EAR, ECCN EAR99 and related export control restrictions.
3.2 Tables of specifications—600H, 750, 750H, 750HH
Table 3-3: Compressor specifications
Compressor 600H 750 750H 750HH
Type Rotary screw
Delivery @ operating pressure
600 cfm
17.0 m3/min)
/ 750 cfm
(21.2 m3/min)
750 cfm
(21.2 m3/min)
750 cfm
(21.2 m3/min)
Maximum operating pressure 150 psig (10.3 bar) 125 psig (8.5 bar) 150 psig (10.3 bar) 175 psig (12.1 bar)
Rated pressure 150 psig (10.3 bar) 125 psig (8.5 bar) 150 psig (10.3 bar) 175 psig (12.1bar)
Cooling Pressurized compressor fluid
Lubricating compressor fluid See
Lubrication guide, compressor
Receiver tank capacity 26 US gallons (98 liters)
Operating tilt (maximum) 15°
Electrical system—engine 24 volt
Electrical system—instrument system 24 volt
Battery (2) 1000 CCA @ 0°F (−18°C)
Alternator 50 amp
Sound Level (US EPA)
1
76 dBA
Sound Level (CE)
2
72 dBA
1
Sound level measured per U.S. 40 CFR Ch. 1 Part 204
2
Sound level measured per 2000/14/EC Outdoor Noise Directive
Table 3-4: Engine specifications
Engine 600 / 750 / 750H / 750HH
Make Caterpillar
Type C9 Tier 3/Stage III
Rated speed 1800 rpm
Horsepower, SAE 300 hp (224 kW)
Cylinders 6
Cycles 4
Bore x stroke 4.41 x 5.87 in (112 x 149 mm)
Displacement 538 cu. in (8.8 liters)
Lubricating system Full pressure fluid
Type of motor oil See Engine Operator’s Manual
Fuel tank capacity 115 U.S. gallons (435 liters)
Engine cooling system capacity 6 U.S. gallons (22.7 liters)
Idle speed 1400 rpm
