2: Description 600H, 750, 750H, 750HH, 825, 900, 900H, 1050 T3 CAT User Manual
02250197-981 R01
34 Subject to EAR, ECCN EAR99 and related export control restrictions.
53 Electronic Control Module error 254-12 No code x x x x
56
Personality Module mismatch 253-02 234-02 x (II)
Check programmable parameters 268-02 111-02 x x
58 J1939 Data Link communications 247-09 639-09
61
High engine coolant temperature derate 015 0110-16
High engine coolant temperature shutdown 016 0110-00
High engine coolant warning 017 0110-15
62
Fuel filter restriction derate 005 0094-15
Fuel filter restriction shutdown 006 0094-16
Fuel filter restriction warning 095 0094-00
High fuel pressure 096 0094-00
64
HIgh inlet temperature derate 025 0172-16
High inlet temperature shutdown 027 0172-05
65
High fuel temperature derate 054 0174-16
High fuel temperature shutdown 055 0174-00
High fuel temperature warning 056 0174-15
72
Injector cylinder #1 fault 1-11 651-11 x x
Injector cylinder #2 fault 2-11 652-11 x x
73
Injector cylinder #3 fault 3-11 653-11 x x
Injector cylinder #4 fault 4-11 654-11 x x
74
Injector cylinder #5 fault 5-11 655-11 x x
Injector cylinder #6 fault 6-11 656-11 x x
00
Either start relay open/short to +batt 545-05 545-05
Either start relay short to ground 545-06 545-06
Table 2-1: Possible performance of active diagnostic codes
Flash
Code
Description of Code
CID-FMI
Code
SPN-FMI
Code
Engine
Misfires
Low
Power
Reduced
Engine
Speed
Engine
Shutdown
(I) The engine will shut down if both speed/timing sensors are lost.
(II) Fuel injection will not occur and the engine will not start. NOTE: Sullair engines are programmed to shut down.
CID = Component Identifier
SPN = Suspect Parameter Number
FMI = Failure Mode Identifier
