600H, 750, 750H, 750HH, 825, 900, 900H, 1050 T3 CAT User Manual 3: Specifications
02250197-981 R01
Subject to EAR, ECCN EAR99 and related export control restrictions. 47
3.8 ID, 4-wheel
Key Part number Qty Description Notes
Drawing notes
A1 DIMENSIONS ARE IN INCHES [] DIMENSIONS ARE IN MILLIMETERS.
A2 ALL DOORS REQUIRE 5 FOOT [1524]CLEARANCE.
A3 REAR DOOR ACCESS BATTERIES AND COOLERS.
A4 REFERENCE A STANDARD 40’ CONTAINER SIZE IS88” WIDE X 89” TALL X 234” LONG.
A5 REFERENCE THREE COMPRESSORS CAN FIT IN A 40’HIGH CUBE CONTAINER.
A6 COOLING AIR INTAKE (3)
A7 WATER CONDENSATE DRAIN (DO NOT PLUG)
A8 ENGINE COOLANT DRAIN
A9 ENGINE OIL DRAIN
A10 COMPRESSOR OIL DRAIN
A11 DRAIN PLUG (4)
A12 TIEDOWN (4)
A13 100% SPILL CONTAINMENT FRAME
A14 FUEL FILL
A15 AUX. FUEL PORTS
A16 LIFTING BAIL
A17 COOLING AIR EXHAUST (3)
A18 AIR CONTROL DOOR
A19 INSTRUMENT PANEL DOOR (COMPASS)
A20 E-STOP
A21 DOOR
A22 OVERALL HEIGHT
A23 SEPARATOR TANK FILTER
A24 ENGINE EXHAUST AIR OUT
A25 ENGINE COOLANT PORT ACCESS COVER
A26 ENGINE AIR INTAKE
A27 UNIT AIR INTAKE
A28 TOWING RING
A29 2” NPT AFTER-COOLED AIR DISCHARGED (AFTER-COOLED MODELS ONLY)
A30 2” NPT STANDARD AIR DISCHARGE
A31 TRACKWIDTH
