Section 12
ILLUSTRATIONS AND PARTS LIST
99
12.10 AIR PIPING SYSTEM- WATER-COOLED
key part
number description number quantity
1 support, air conn and cond drn 02250045-613 1
2 insert, nylon tubing 1/4”od 02250052-841 2
3 tube, nyl .25 od x .040”w 02250054-861 1
4 elbow, tube m-2 x 2 w/1/4”tap 02250110-165 1
5 separator, water 2” (I) 02250126-818 1
6 tube, separator disch top 2” 02250129-728 1
7 tube, mpv to wcaftclr 2” 02250129-733 1
8 tube, wcaftclr to moistsep 2” 02250129-734 1
9 connector, 1/4t x 1/8 npt str 250018-427 1
10 elbow, 90 1/4t pls x 1/4 npt m 250018-430 2
11 bushing, red stl 3/4 x 1/4 807603-010 1
12 connector, tube-m 2 x 2 810232-200 1
13 elbow, tube 90 deg m 2 x 2 810532-200 3
14 elbow, tube str thrd 2 x 2 1/2 811632-250 1
15 capscr, hex gr5 1/2-13 x 1 1/2 829108-150 2
16 washer, spr lock reg pltd 1/2 837808-125 2
17 washer, pl-b reg pltd 1/2 838208-112 2
(I) For maintenance on water separator no. 02250126-818, order replacement kit no. 02250129-174,
and/or automatic drain kit no. 02250129-175.
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE THE SERIAL NUMBER OF COMPRESSOR
