Section 12
ILLUSTRATIONS AND PARTS LIST
121
12.17 CONTROL BOX- SUPERVISOR CONTROLLER (CONTINUED)
key part
number description number quantity
34 plug, straight thread 3/4-16 viton 250042-623 1
35 adapter, female pipe 1/2 x 1/4 811504-025 2
36 nut, hex f pltd 5/16-18 825305-283 8
37 nut, hex f pltd 3/8-16 825306-347 4
38 nut, hex metric m4 x .7 825904-070 8
39 screw, hex ser washer 5/16-18 x 3/4 829705-075 4
40 screw, hex ser washer 3/8-16 x 1 829706-100 4
41 screw, tc-f pan #8-32 x 1/2 835601-050 8
42 washer, spr lock-metric pltd m4 838804-090 8
43 bulkhead, pipe 1/8” npt 841500-002 2
44 lug, scrulug kpa-25 4-1/0 849215-025 1
45 bushing, red pltd 1/4 x 1/8 867100-005 2
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE THE SERIAL NUMBER OF COMPRESSOR
