Section 12
ILLUSTRATIONS AND PARTS LIST
78
12.2 RECOMMENDED SPARE PARTS LIST (CONTINUED)
DESCRIPTION KIT NUMBER QTY
kits, repair for compressor shaft seal:
STANDARD UNIT SEAL KITS-
kit, seal repl d20c dbl tfe lip 02250057-037 1
kit, tool-d20c gd lip seal repl 02250078-694 1
SPIRAL VALVE UNIT SEAL KITS-
kit, repl-seal dxr20a dd tfe lp 02250086-865 1
kit, tool-d20c dd lip sl repl 02250087-302 1
kit, repair for air inlet valve 02250060-988 022250053-273 1
kit, repair for pressure regulator 250017-280 250019-453 1
kit, repair for blowdown valve 02250100-042 02250100-042 1
kit, repair for solenoid valve 02250125-657 02250125-829 1
•kit, replacement for solenoid valve coil 02250125-657 02250125-861 1
kit, repair for moisture separator 02250100-365 02250129-173 1
•kit, autodrain for separator 02250100-365 02250129-175 1
kit, repair for moisture separator 02250126-818 02250129-174 1
•kit, autodrain for separator 02250126-818 02250129-175 1
replacement element for drive coupling 02250129-707 1
kit, spiral valve actuator 608311-001 1
kit, spiral valve tool 02250052-625 1
manual, Sequencing & Protocol (III) 02250139-197 1
fluid, SRF 1/4000 (5 gal/ 19l) 250019-662 (IV)
lubricant, Sullube (Std.) (5 gal/ 19l) 250022-669 (IV)
lubricant, 24 KT (5 gal/ 19l) 02250051-053 (IV)
kit, repair for pressure regulator 408275 (spiral valve) 250028-693 1
(III) This document is required to program your personal computer to communicate with the Supervisor
panel.
(IV) For proper amount of fluid fill, please consult Lubrication Guide in Section 3, Specifications.
Mixing of other lubricants within the compressor unit will void all warranties!
PLEASE NOTE: WHEN ORDERING PARTS, ALWAYS INDICATE SERIAL NUMBER OF COMPRESSOR
