Section 3
11
SPECIFICATIONS
SPECIFICATIONS
Pay attention to the Minimum and Maximum operating conditions before installing and operating the dryer.
If your application does not match the above criteria, contact your Sullair distributor and they will be able to
provide the right dryer for your application.
3.1 PRODUCT PICTURE / PRODUCT FINAL ASSEMBLY DRAWING
Normal Operating Pressure 100 PSIG
Normal Operating Temperature 100 Deg. F
Normal Ambient Temperature 100 Deg. F
Maximum Operating Pressure 230 PSIG
Minimum Operating Pressure 75 PSIG
Maximum Ambient Temperature 120 Deg. F
Minimum Ambient Temperature 40 Deg. F
Maximum Operating Temperature 150 Deg. F
