SECTION 5 PRINCIPLE OF OPERATION
25
5.9 ED—RC 175
KEY PART NUMBER DESCRIPTION QTY
1 M-CMP-0200-230-1-60-A COMPRESSOR 1
2 M-CON-0175 CONDENSER 1
3 M-FMT-0200-230-1-50 FAN MOTOR 1
4 M-FAN-0200 FAN BLADE 1
5 M-GRL-0200 FAN GRILL 1
6 M-DRI-0200 DRIER-DEHYDRATOR 1
7 M-EXC-0200 HEAT EXCHANGER 1
8 M-WHC-0200
EVAPORATOR (WATER HEAT
EXCHANGER) 1
9 M-INL-0150 FLEXIBLE STEEL TUBE (INLET) 1
10 M-OTL-0150 FLEXIBLE STEEL TUBE (OUTLET) 1
11 M-EXV-200 EXPANSION VALVE 1
12 M-HPS-0200
HIGH PRESSURE SECURITY
SWITCH 1
13 M-FNS-0200 FAN ON/OFF SWITCH 1
14 M-WPS-3000 WATER PRESSURE SWITCH 1
15 M-PMP-0325-230-1-60 WATER PUMP 1
16 M-WTA-0175 WATER TANK 1
17 M-LIN-3000 LEVEL INDICATOR 1
18 M-WAG-3000 WATER GAUGE 1
19 M-DGC-3000 DIGITAL CONTROLLER 1
20 M-ONB-0200 ON/OFF BUTTON 1
21 M-MNS-0700 MAIN SWITCH 1
22 M-TMR-3000 TIMER 1
23 M-SLV-250-230 SELENOID VALVE 1
24 M-CFR-0200 CABINET FRONT 1
25 M-CSI-0200 CABINET SIDE 2
26 M-CRE-0200 CABINET REAR 1
27 M-CTO-0200 CABINET TOP 1
28 M-CBA-0200 CABINET BASE 1
29 M-CBL-0200 CABINET LEG 4
30 M-HP1-0200 CABINET HORIZONTAL PROFILE 1 2
31 M-HP2-0200 CABINET HORIZONTAL PROFILE 2 2
32 M-CTC-3000 CABINET TOP CORNER 4
33 M-CPS-3000 CABINET HANDLE 8
34 M-STU-3000 CABINET STUD AND NUT 12
35 M-FAS-3000 CABINET FASTENER 12
36 M-NUT-3000 CAGE NUT AND SCREW 16
37 M-SCR-3000 SCREW TYPE 2 16
38 M-CSR-0200-230-1-60 COMPRESSOR START RELAY 1
39 M-WST-3000 WATER PRESSURE SWITCH TIMER 1
40 M-CNT-0400 CONTACTOR 1
41 M-WPC-3000 WATER PUMP CONTACTOR 1
42 M-CSC-200-230-1-60 COMPRESSOR START CAPACITOR 1
43 M-RUN-0325-230-1-60 RUN CAPACITOR 1
DECAL CFM
DRYER PART
NUMBER
POWER
RATINGS
COOLING
RC175 175 02250193-865
220V/1Ph/
50Hz AIR COOLED
RC175 175 02250193-821
208-230V/
1Ph/60Hz AIR COOLED
KEY PART NUMBER DESCRIPTION QTY
