SECTION 5 PRINCIPLE OF OPERATION
37
5.15 ED—RC 700
KEY PART NUMBER DESCRIPTION QTY
1 SEE REF. TABLE COMPRESSOR 1
2 M-CON-0700 CONDENSER 1
3 SEE REF. TABLE FAN MOTOR 1
4 M-DRI-1000 DRIER-DEHYDRATOR 1
5 M-EXC-0200 HEAT EXCHANGER 3
6 M-WHC-1000 EVAPORATOR (WATER HEAT EXCHANGER) 1
7 M-EXV-1000 EXPANSION VALVE 1
8 M-HPS-1000 HIGH PRESSURE SECURITY SWITCH 1
9 M-FNS-0400 FAN ON/OFF SWITCH 2
10 M-LPS-1000 LOW PRESSURE SWITCH 1
11 M-THS-0325 THERMOSTATIC SWITCH 1
12 M-WPS-3000 WATER PRESSURE SWITCH 1
13 SEE REF. TABLE WATER PUMP 1
14 M-WTA-0700 WATER TANK 1
15 M-LIN-3000 LEVEL INDICATOR 1
16 M-WAG-3000 WATER GAUGE 1
17 M-DGC-3000 DIGITAL CONTROLLER 1
18 M-ONB-3000 ON/OFF BUTTON 1
19 M-MNS-0700 MAIN SWITCH 1
20 M-TMR-3000 TIMER 1
21 M-SLV-3000-24 SELENOID VALVE 1
22 M-MMV-1000 MEMBRANE VALVE 1
23 M-MMM-1000 MEMBRANE 1
24 M-CFR-0850-C CABINET FRONT 1
25 M-CSD-0850-C CABINET SIDE 2
26 M-CRE-0850-C CABINET REAR 1
27 M-CTO-0850-C CABINET TOP 1
28 M-CBA-0850-C CABINET BASE 1
29 M-CBL-0850-C CABINET LEG 4
30 M-HP1-0850-C CABINET HORIZONTAL PROFILE 1 2
31 M-HP2-0850-C CABINET HORIZONTAL PROFILE 2 2
32 M-CTC-3000 CABINET TOP CORNER 4
33 M-CPS-3000 CABINET HANDLE 8
34 M-STU-3000 CABINET STUD AND NUT 12
35 M-FAS-3000 CABINET FASTENER 12
36 M-NUT-3000 CAGE NUT AND SCREW 16
37 M-SCR-3000 SCREW TYPE 2 16
38 M-TRF-1000 TRANSFORMER 1
39 M-PPR-1000 PHASE PROTECTION RELAY 1
40 M-CNT-0850 CONTACTOR 1
41 M-FCN-1000 FAN CONTACTOR 2
42 M-WPC-3000 WATER PUMP CONTACTOR 1
43 M-SEC-1000 SECONDARY CONTACT 1
44 M-WPP-1000 WATER PUMP PROTECTOR 1
45 SEE REF. TABLE COMPRESSOR OVERLOAD PROTECTOR 1
46 M-FOP-3000 FAN OVERLOAD PROTECTOR 2
47 M-WST-3000 WATER PRESSURE SWITCH TIMER 1
DECAL CFM
DRYER PART
NUMBER
POWER
RATINGS
COOLING COMPRESSOR FAN MOTOR WATER PUMP
COMPRESSOR
OVERLOAD
PROTECTOR
RC500 500 02250193-826 230V/3Ph/60Hz AIR COOLED M-CMP-0700-230-3-60-A M-FMT-0700-230-3-60-A M-PMP-1000-230-3-60-A M-COP-0700-230-3-60-A
RC500 500 02250193-907 400V/3Ph/50Hz AIR COOLED M-CMP-0700-460-3-50-A M-FMT-0700-460-3-50-A M-PMP-1000-400-3-50-A M-COP-0700-460-3-50-A
RC500 500 02250193-966 460V/3Ph/60Hz AIR COOLED M-CMP-0700-460-3-60-A M-FMT-0700-460-3-60-A M-PMP-1000-460-3-60-A M-COP-0700-460-3-60-A
RC500 500 02250194-124 575V/3Ph/60Hz AIR COOLED M-CMP-0700-575-3-60-A M-FMT-0700-575-3-50-A M-PMP-1000-575-3-60-A M-COP-0700-575-3-60-A
RC500 500 02250193-826 230V/3Ph/60Hz AIR COOLED M-CMP-0700-230-3-60-A M-FMT-0700-230-3-60-A M-PMP-1000-230-3-60-A M-COP-0700-230-3-60-A
KEY PART NUMBER DESCRIPTION QTY
