SECTION 5 PRINCIPLE OF OPERATION
51
5.22 ED—RC 1200 WATER COOLED
KEY PART NUMBER DESCRIPTION QTY
1 M-CMP-1600-460-3-60-A COMPRESSOR 1
2 M-CON-1200-W CONDENSER 1
3 M-DRI-1200 DRIER-DEHYDRATOR 1
4 M-EXC-1200 HEAT EXCHANGER 3
5 M-WHC-1200
EVAPORATOR (WATER HEAT
EXCHANGER) 1
6 M-EXV-1250 EXPANSION VALVE 1
7 M-HPS-6000 HIGH PRESSURE SECURITY SWITCH 1
8 M-LPS-6000 LOW PRESSURE SWITCH 1
9 M-THS-3000 THERMOSTATIC SWITCH 1
10 M-WPS-3000 WATER PRESSURE SWITCH 1
11 M-CMP-1200-460-3-60 WATER PUMP 1
12 M-WTA-1200 WATER TANK 1
13 M-LIN-3000 LEVEL INDICATOR 1
14 M-WAG-3000 WATER GAUGE 1
15 M-DGC-3000 DIGITAL CONTROLLER 1
16 M-ONB-3000 ON/OFF BUTTON 1
17 M-MNS-3000 MAIN SWITCH 1
18 M-TMR-2400 TIMER 1
19 M-SLV-2400-24 SELENOID VALVE 1
20 M-MMV-2400 MEMBRANE VALVE 3
21 M-MMM-2400 MEMBRANE 3
22 M-CFR-1200-C CABINET FRONT 1
23 M-CSD-1200-C CABINET SIDE 2
24 M-CRE-1200-C CABINET REAR 1
25 M-CTO-1200-CW CABINET TOP 1
26 M-CBA-1200-C CABINET BASE 1
27 M-CBL-1200 CABINET LEG 4
28 M-HP1-1200-C CABINET HORIZONTAL PROFILE 1 2
29 M-HP2-1200-C CABINET HORIZONTAL PROFILE 2 2
30 M-CTC-3000 CABINET TOP CORNER 4
31 M-CPS-3000 CABINET HANDLE 8
32 M-STU-3000 CABINET STUD AND NUT 12
33 M-FAS-3000 CABINET FASTENER 12
34 M-NUT-3000 CAGE NUT AND SCREW 16
35 M-SCR-3000 SCREW TYPE 2 16
36 M-TRF-6000 TRANSFORMER 1
37 M-PPR-6000 PHASE PROTECTION RELAY 1
38 M-CNT-0850-460-3-60-A CONTACTOR 1
39 M-WPC-3000 WATER PUMP CONTACTOR 1
40 M-SEC-3000 SECONDARY CONTACT 1
41 M-WPP-6000 WATER PUMP PROTECTOR 1
42 M-COP-1200
COMPRESSOR OVERLOAD
PROTECTOR 1
43 M-WST-3000 WATER PRESSURE SWITCH TIMER 1
44 M-WVF-3000 WATER VALVE 1
DECAL CAPACITY DRYER PART NUMBER POWER RATINGS COOLING
RC 1200 1200 CFM 02250193-936 400V/3PH/50HZ WATER COOLED
RC 1200 1200 CFM 02250194-101 460V/3PH/60HZ WATER COOLED
RC 1200 1200 CFM 02250194-136 575V/3PH/60HZ WATER COOLED
KEY PART NUMBER DESCRIPTION QTY
