SECTION 5 PRINCIPLE OF OPERATION
53
5.23 ED—RC 1600 AIR COOLED
KEY PART NUMBER DESCRIPTION QTY
1 M-CMP-1200-460-3-60-A COMPRESSOR 1
2 M-CON-1600 CONDENSER 1
3 M-FMT-1600-460-3-60 FAN MOTOR 2
4 M-DRI-2400 DRIER-DEHYDRATOR 1
5 M-EXC-2000 HEAT EXCHANGER 3
6 M-WHC-1000
EVAPORATOR (WATER HEAT
EXCHANGER) 1
7 M-EXV-2000 EXPANSION VALVE 1
8 M-HPS-6000 HIGH PRESSURE SECURITY SWITCH 1
9 M-FNS-0400 FAN ON/OFF SWITCH 2
10 M-LPS-6000 LOW PRESSURE SWITCH 1
11 M-THS-3000 THERMOSTATIC SWITCH 1
12 M-WPS-3000 WATER PRESSURE SWITCH 1
13 M-PMP-1600-460-3-60 WATER PUMP 1
14 M-WTA-1600 WATER TANK 1
15 M-LIN-3000 LEVEL INDICATOR 1
16 M-WAG-3000 WATER GAUGE 1
17 M-DGC-3000 DIGITAL CONTROLLER 1
18 M-ONB-3000 ON/OFF BUTTON 1
19 M-MNS-3000 MAIN SWITCH 1
20 M-TMR-3000 TIMER 1
21 M-SLV-2400-24 SELENOID VALVE 1
22 M-MMV-2400 MEMBRANE VALVE 3
23 M-MMM-2400 MEMBRANE 3
24 M-CFR-2000-C CABINET FRONT 1
25 M-CSD-2000-C CABINET SIDE 2
26 M-CRE-2000-C CABINET REAR 1
27 M-CTO-2000-C CABINET TOP 1
28 M-CBA-2000-C CABINET BASE 1
29 M-CBL-6000-C CABINET LEG 4
30 M-HP1-2000-C CABINET HORIZONTAL PROFILE 1 2
31 M-HP1-2000-C CABINET HORIZONTAL PROFILE 2 2
32 M-CTC-3000 CABINET TOP CORNER 4
33 M-CPS-3000 CABINET HANDLE 8
34 M-STU-3000 CABINET STUD AND NUT 12
35 M-FAS-3000 CABINET FASTENER 12
36 M-NUT-6000 CAGE NUT AND SCREW 16
37 M-SCR-3000 SCREW TYPE 2 16
38 M-TRF-6000 TRANSFORMER 1
39 M-PPR-6000 PHASE PROTECTION RELAY 1
40 M-CNT-3000-460-3-60-A CONTACTOR 1
41 M-FCN-1200 FAN CONTACTOR 2
42 M-WPC-3000 WATER PUMP CONTACTOR 1
43 M-SEC-3000 SECONDARY CONTACT 1
44 M-WPP-6000 WATER PUMP PROTECTOR 1
45 M-COP-1600
COMPRESSOR OVERLOAD
PROTECTOR 1
46 M-FOP-2000 FAN OVERLOAD PROTECTOR 2
47 M-WST-3000 WATER PRESSURE SWITCH TIMER 1
DECAL CAPACTIY DRYER PART NUMBER POWER RATINGS COOLING
RC 1600 1600 CFM 02250193-912 400V/3PH/50HZ AIR COOLED
RC 1600 1600 CFM 02250193-971 460V/3PH/60HZ AIR COOLED
RC 1600 1600 CFM 02250194-129 575V/3PH/60HZ AIR COOLED
KEY PART NUMBER DESCRIPTION QTY
