INSTALLATION, START-UP & MAINTENANCE MANUAL
MODEL NO.: SD-820 / SD-1710
REV 1 – AUGUST 03,.2001
Page 11
SECTION 2 INSTALLATION
2.1 SET-UP AND INSTALLATION
Once at the installation location, the adsorption dryers of the series SD-820 – SD-
1710, which are supplied with a base frame, must be positioned so that the side from
which it is to be operated is easily accessible. The piping is to be connected to the
adsorption dryer at a light slope. A shut-off valve is to be installed on the inlet and outlet
sides of the adsorption dryer. Also, a by-pass pipe with an additional shut-off valve
should be mounted onto the adsorption dryer, in order to be able to guarantee an
uninterrupted supply of compressed air in case the adsorption dryer breaks down.
Should vibrations occur on the installation location, the adsorption dryer is to be placed
onto vibration dampers.
Since the adsorption dryer has already been completely wired at our factory, the
customer only has to connect the power supply cable to the terminal strip according to
the supplied wiring diagrams.
* Advice
Should you still have questions regarding installation, you can request
installation blueprints separately from
S
S
u
u
l
l
l
l
a
a
i
i
r
r
®®
MichiganCity,Indiana
