INSTALLATION, START-UP & MAINTENANCE MANUAL
MODEL NO.: SD-820 / SD-1710
REV 1 – AUGUST 03,.2001
Page 26
SECTION 5 DRYER FLOW CAPACITY AND PURGE ADJUSTMENT
5.1 DRYER FLOW CAPACITY
Model Selection Chart
Average Inlet Air Flow (SCFM)
Based upon 100 F Inlet Air Temperature Inlet Air Pressure
MODEL
Max. Inlet Air
Pressure
(Psig)
80 90 100 110 120 130 140
SD 220 150 175 202 220 253 272 293 310
SD 300 150 230 265 300 340 362 390 416
SD 400 150 305 352 400 438 470 510 544
SD 500 150 378 435 500 550 590 635 675
SD 600 150 485 555 600 700 760 810 850
SD820 150 640 735 820 890 960 1035 1105
SD1050 150 830 960 1050 1215 1325 1410 1590
SD1200 150 980 1095 1200 1305 1415 1520 1615
SD1450 150 1110 1280 1450 1510 1700 1825 1950
SD1710 150 1325 1515 1710 1810 1945 2080 2230
SD2000 150 1530 1720 2000 2100 2220 2390 2530
SD2350 150 1875 2165 2350 2700 2930 3150 3350
SD2750 150 2085 2400 2750 2990 3225 3490 3720
SD3400 150 2775 3080 3400 3650 3950 4250 4540
1. Higher pressures available as an option. Consult factory
2. Based on – 40 F PDP, 10 Minute NEMA cycle, activated alumina and average inlet air flow.
5.2 CORRECTION FACTOR FOR INLET TEMPERATURE
TEMPERATURE
DEGREES F
80 90 100 105 110 115 120
Correction Factor 1.1 1.1 1.0 0.83 0.69 0.565 0.455
To correct for an inlet temperature other than 100 F multiply dryer capacity by the
temperature correction factor listed above.
