Service Manual SummaCut D60-D120
1. USB interface: - This interface is based on the standards specified in Universal
Serial Bus Specifications Revision 1.1. It allows a high-speed serial bi-directional
communication between the host computer and the cutter.
2. RS-232-C Port: - This DB-9P connector provides the communication link
between the cutter and a host computer. It allows bi-directional communication
between the host computer and the cutter.
3. Parallel Port: - This IEEE1284 -B connector provides a bi-directional
communication link between the cutter and a host computer.
Note: only one interface can be active at a time.
The first port that receives data will be the active interface until the cutter is reset.
4. Power ON/OFF switch - This rocker switch sets the cutter’s power to ON or OFF.
To switch the power ON, press the “I” side of the rocker switch. To switch the
power OFF, press the “O” side of the rocker switch.
5. Power Entry Module: - The fuse box and the AC power cord receptacle are
located in the power entry module.
The power-up procedure is explained in detail in Section 1.6.
6. Fuse box: - For information about changing of the fuse, see Section 4.2.
7. Roll Media Guide Bushes: - The two guide bushes serve to keep the media roll in
place when media is pulled from the roll.
8. Media Flanges: - The media flanges ensure proper routing of the media roll.
9. Media Support Roller: - Rotating support rollers for the media roll.
10. Alignment Strip: - Rear alignment strip for easier media loading.
Introduction I-5
