Service Manual SummaCut D60-D120
1.1.3. THE X KEY
The
x key (cancel key) cancels the current operation
Pressing this key when the cutter is cutting stops the current job.
1.1.4.
THE V Key
The
V Key (confirm key) confirms a selected menu or a changed menu item.
As long as this key is not pressed a changed value of a menu item is not saved
internally and can will be lost if the menu is left.
1.1.5.
THE TEST Key
If there is a certain test routine in a submenu, then it can be activated to start it.
1.1.6.
THE jogging Keys
The use of the jogging keys varies according to the operation in progress.
For example, when working with different submenus, the
or jogging key is
used to select the next or previous submenu.
When in a submenu the values can be changed by pressing
or .
When the cutter is normal operation, then by pressing either one of the jogging keys,
the origin can be changed.
Keyboardcontrols 1-3
