SummaCut D60-D120 Service Manual
1.2. COMMON MENU ITEMS
Following paragraphs explain the different submenus.
1.2.1 VELOCITY
The VELOCITY submenu is used to set or modify the velocity of the tool.
The default velocity is 700 mm/s (20 ips).
After pressing the
key then press the or jogging key until the desired
speed is displayed on the LCD and press
to confirm.
The velocity can be set between 50 mm/s (2 ips) and 800 mm/s (40 ips).
On the LCD, the active plotting speed is marked with an “*”.
1.2.2 PEN PRESSURE
The PEN PRESSURE parameter is used to set or modify the cutting pressure of the
pen.
The default pen pressure value is 80 grams.
After pressing the
key then press the or jogging key until the desired
pressure is displayed on the LCD and press
to confirm.
The pen pressure can be set between 0 and 400 grams.
The pen pressure value is set in 5 gram increments.
On the LCD, the active pen pressure is marked with an “*”.
1.2.3 KNIFE PRESSURE
The KNIFE PRESSURE parameter is used to set or modify the cutting pressure of the
knife.
The default knife pressure value is 120 grams.
After pressing the
key then press the or jogging key until the desired
pressure is displayed on the LCD and press
to confirm.
The knife pressure can be set between 0 and 400 grams.
The knife pressure value is set in 5 gram increments.
On the LCD, the active knife pressure is marked with an “*”.
1-4 Keyboardcontrols
