SummaCut D60-D120 Service Manual
1.2.7 RESET
The RESET instruction performs a complete reset of the cutter. Press the
key to
execute a reset.
1.2.8 RECUT
The RECUT instruction recuts the last file sent to the cutter (provided that it fitted into
the buffer). Press the
key to execute the instruction.
1.2.9 LOAD
The LOAD instruction is used to initiate a load sequence. Press the
key to
execute. First the origin can be changed if necessary. Press the
or jogging key
to change the origin in the Y-direction. Press the
or jogging key to change
the origin in the x-direction. Press the
key to confirm. Then the media window
can be changed. Press the
or jogging key to change the length of the
window or press the
key to change the value of the length of the media window.
The
or jogging key change the value in steps of 100mm, the or
jogging key change it in steps of 10mm (When the machine is set up in English units,
the step sizes are respectively 0.5” and 2.5”). Then press the
key to finish the
load procedure.
1.2.10 ALIGN LOAD
The Align load sub menu is used for contour cutting. Refer to section 3 in the User’s
manual for the complete explanation on contour cutting. Section 1.3.11 explains how to
change the align method. Press the
key to execute.
1.2.11 SYSTEM SETUP
The SYSTEM SETUP submenu covers the menu items you normally only need when
establishing the initial set-up e.g. when you install the cutter in combination with the
software you use.
Press the confirmation key to access the different submenu items, which are explained
in section 1.3.
1-6 Keyboardcontrols
