Service Manual SummaCut D60-D120
1.2.4 KNIFE OFFSET
The KNIFE OFFSET parameter is used to set or modify the distance between the knife
blade tip and the centre axis.
The default knife offset value is .45 mm.
After pressing the
key then press the or jogging key until the desired
knife offset is displayed on the LCD and press
to confirm.
The value can be set between 0 and 1 mm.
Make sure that the selected knife offset value matches that of the knife. Some
fine-tuning may be necessary because of the mechanical tolerances on the knife. To
verify the knife offset, a test can be cut by pressing on the
key.
If the offset value is set too low, the rectangles will not close.
When the offset value is set too high, the rectangles will be distorted.
The offset test is illustrated below.
1.2.5 POUNCING PRESSURE
The POUNCING PRESSURE submenu is used to set or modify the pouncing pressure
of the pouncing tool.
The default pouncing pressure value is 120 grams.
After pressing the
key then press the or jogging key until the desired
pressure is displayed on the LCD and press
to confirm.
The pouncing pressure can be set between 0 and 400 grams.
The pouncing pressure value is set in 5 gram increments.
On the LCD, the active pouncing pressure value is marked with an “*”.
Pouncing pressure set-up is explained in detail in section 1.8.1.
1.2.6 POUNCING GAP
The pouncing gap submenu is used to set or modify the distance between the pounced
wholes. This routine applies to the pouncer only.
The default pouncing gap value is 1 mm.
After pressing the
key then press the or jogging key until the desired
pouncing gap is displayed on the LCD and press
to confirm.
The value can be set between 1 mm and 50 mm.
On the LCD, the active pouncing gap value is marked with an “*”.
Keyboardcontrols 1-5
