22 Sun Fire X4150 Server Embedded Lights Out Manager Administration Guide • September 2007
TABLE 3-9 shows a detail of the Summary table that summarizes the status of the
temperature sensors.
TABLE 3-10 shows a detail of the Summary table that summarizes the status of the
DC power supply lines.
TABLE 3-11 shows a detail of the Summary table that summarized the status of the
systems power supplies.
TABLE 3-9 Detail of the Summary Table Showing the Status of the Temperature Sensors.
CPU 0 Temp :too high
Temperature Status
CPU 1 Temp :ok
Ambient Temp0 :ok
TABLE 3-10 Detail of the Summary Table Showing the Status of the Power Supply Lines.
Vcc 12V :ok
Vtt 1.2V :ok
MCH 1.5V :ok
Vcc 3.3V :ok
Voltage Status
Vcc 5V :ok
NIC Vtt 1.2V :ok
Vcc 3.3V STB :ok
Vcc 2.5V STB :ok
Vcc 1.8V :ok
TABLE 3-11 Detail of the Summary Table Showing the Status of the Power Supplies.
PS0 Under Volt :ok
PS1 Under Volt :ok
Power Status
PS0 OC Fault :ok
PS1 OC Fault :ok
Power Supply 0 :ok
Power Supply 1 :ok
