8 Sun Fire X4150 Server Product Notes • February 2010
Note – Refer to “Issues Fixed in Tools and Drivers DVD Version 2.2.0” on page 68
for information on issues that have been fixed with this release.
Tools and Drivers DVD v2.1.0
The firmware versions for Tools and Drivers CD 2.1.0 include:
■ BIOS version: 1ADQW054
■ SP version: 2.0.2.6
Prior to installing any supported E0 stepping CPU on an ILOM system, you must
first upgrade the system to 1ADQW054 BIOS. Refer to “Identifying E0 Stepping
Processors” on page 19.
Note – Refer to “Issues Fixed in Tools and Drivers DVD Version 2.1.0” on page 69
for information on issues that have been fixed with this release.
Tools and Drivers CD v2.0
Tools and Drivers CD 2.0 contains firmware for both Embedded Lights Out Manager
(ELOM) and Integrated Lights Out Manager (ILOM) and supports ELOM to ILOM
migration.
Note – If you are using the Qimonda Memory 2GB/DDR2 HYS72T256421EFA-3S-
C2 then you must update to ILOM BIOS 1ADQW052 or ELOM BIOS 1ADQW027.
The firmware versions for ILOM and ELOM are listed in
TABLE 1:
Please note the following regarding the ELOM firmware:
■ If you do not want to transition to ILOM at this time, you can update your system
to the ELOM firmware version shown in the table.
■ If you do plan to transition to ILOM, you first need to update ELOM with the
following transitional ELOM firmware file: X4150-026-450.
TABLE 1 Tools and Drivers CD 2.0 Firmware Versions
Firmware Type ILOM ELOM
BIOS version
1ADQW052 1ADQW026
SP version
2.0.2.6 4.0.10
