Functional Details 65
E500 Series Universal Low-Power Inverter
This group of parameters defines the cutting start delay and stop delay, which is
related to the length of the first plate and last plate.
This parameter is used to select if it is needed to enable liner cutter function.
0: Disable cutter function
1: Liner cutter mode 1
(this mode is applicable to high-speed wire mode)
2: Liner cutter mode 2
(this mode is applicable to the medium-speed wire mode)
This group of parameters defines the forward and backward time in the next
cycle in the reciprocating mode.
This
group of parameters is used to set the conditions for engaging or disengaging
high-frequency relay.
When
the inverter’s output frequency is higher than the frequency set by [F6.09]*,
the high-frequency relay is engaged. When it is lower than the frequency set by
[F6.10], the high-frequency relay is disengaged. In the liner cutting mode 2,
when the inverter’s output frequency is higher than frequency set by [F6.11], the
high-frequency relay is disengaged.
F6.05 Reserve
F6.06 Liner cutting running mode Setting range: 0 ~2
F6.03 Start delay Setting range:: 0.01~10.00
F6.04 Stop delay Setting range: 0.01~10.00
F6.07 Forward time Setting range: 0~60.0Sec
F6.08 Return time
Setting range: 0~60.0Sec
F6.09 High-frequency relay start frequency Setting range: [F6.10]~100%
F6.10 High-frequency relay disconnection frequency 1 Setting range: 0~[F6.09]
F6.11 High-frequency relay disconnection frequency 2 Setting range: 100~200%
