18 Function Parameter Table
E500 Series Universal Low-Power Inverter
Monitoring
code
Content Unit
d-10 Input terminal status
d-11 Module temperature ºC
d-12 Analog output AO V
d-13 Timer value
d-14 Reserve
d-15 Reserve
d-16 Reserve
d-17 Reserve
d-18 Reserve
d-19 Reserve
d-20 Reserve
d-21 Reserve
d-22 Reserve
d-23 First fault record
d-24 Second fault record
d-25 Third fault record
d-26 Forth fault record
d-27 Output frequency at the time of recent fault Hz
d-28 Output currency at the time of recent fault A
d-29 Output voltage at the time of recent fault V
d-30 DC voltage at the time of recent fault V
d-31 Module temperature at the time of recent fault
4.4 Simple operation of the inverter
4.4.1 Initial setting
(1) Channel selection for frequency input ([F0.00])
Inverter’s initial setting varies from each other according to different models.
When the parameter is set to 0, the inverter’s frequency setting will be set
through the panel digit.
(2) Selection of running command input channel ([F0.02])
The inverter’s initial setting varies according to different models. When this
parameter is set to [F0.02] =###0, the inverter’s start and stop control will be
completed through key on the operating panel.
STOP
RUN
