Function Parameter Table 23
E500 Series Universal Low-Power Inverter
Parameter
Type
Function
Code
Name
Setting Range and
Description
Minimum
unit
Default
setting
Modifica-
tion limit
Input and output parameter group
F1.15
OC and relay
output
characteristic
selection
LED Units: OC
output selection
0: OC output
positive
characteristics
1: OC output
negative
characteristics
LED Tens: relay
output selection
0: relay output
positive
characteristics
(normally open)
1: relay output
negative
characteristics
(normally closed)
1 0000
F1.16
Relay action
delay
0.0S~5.0S 0.1 0
F1.17
Frequency
reaching detecting
amplitude
0.0 ~ 20.0Hz 0.1 5.0
F1.18
FDT
( frequency
level) setting
0.0 ~[F0.04] 0.1 10.0
F1.19
FDT output
delay time
0.0 ~ 5.0 Sec 0.1 2.0 ×
F1.20
Overload alarm
level
50 ~200 (%) 1 110
F1.21
Overload alarm
delay time
0.0 ~ 60.0 Sec 0.1 2.0 ×
F1.22 Reserve
F1.23 Reserve
F1.24
Batter number
of terminal
machine
1~100 1 10
F1.25
Designated
counting value
1~[F1.26] 1 5
F1.26
Final counting
value
[F1.25]~60000 1 100
F1.27 Reserve
