10
5 Mechanical Installation
5.1 Unpacking and Inspection
Check the scope of delivery for completeness according to the packing list. The
following items should be included:
Fig. 5-1 Scope of delivery
Quick user manual, delivery inspection report,
packing list, warranty card, and certificate
12, used for binding the cables
4, M6 x 45, used for wall-mounting to fasten the
device on the metal surface
4, M6 x 60, used for wall-mounting to fasten the
device on the concrete wall
6x120Ω
Note: if there are more than 15 devices connected
on the RS485 bus, it is recommended to connect a
120Ω terminal resistor in parallel on the A and B
lines at the head (or tail end) of the bus
M5x10, used for grounding connection
