7 Commissioning
7.1 Check before Commissioning
No.
Item
Result
1
All cables are intact, well insulated, and appropriately
dimensioned
□
2
All cables are connected correctly and firmly
□
3
The polarity of the power supply cable is correct. The
ground cable is reliably grounded
□
4
Seal the gaps at the bottom of the waterproof terminals
with fireproof mud
□
7.2 Commissioning Steps
When all the foregoing items meet requirements, commission the COM100 for
the first time.
No.
Step
Result
1
Inspection before commissioning
□
2
Turn the micro-circuit breaker inside the COM100 to the ON
position.
□
3
Check whether the indicators of Logger1000 inside the
COM100 normally flash.
□
4
Connect the debugging PC to the "ETH" port of the
Logger1000 via the network cable (default IP address of
"ETH": 12.12.12.12).
Log in the Web at 12.12.12.12 through the IE or Chrome
browser.
□
5
Make sure the communication cable connecting the device
and the Logger1000 inside the COM100 is firmly in place,
and connect the DC circuit breaker of the inverter to ensure
the inverter is supplied with power.
□
6
Configure related parameters referring to the user manual of
Logger1000.
□
7
Enable the DHCP service of the router.
□
8
Set the iSolarCloud address if data needs to be uploaded to
cloud server.
□
