Sungrow SBR064 - Page 35

27
step 11 Place the top cover and fix it with the screws provided.
step 12 (Optional) Install the side covers.
When 4 or more than 4 battery modules are installed in one base, side covers are
required.
- - End
User Manual 4 Mounting
