Sungrow SD175HV - Moving the Converter

16
FFiigguurree 44--11 Installation Tools
IItteemm
DDeessccrriippttiioonn
a
M2
b M4/M6
c
Drill bit: φ12、φ14
d Includes sleeve with opening size 16mm
e
Opening:13mm, 16mm
f Range≥1500Vdc
4.4 Moving the Converter
Move the converter to the specified position before installation. When moving the con-
verter, follow the instructions below.
4 Mechanical Mounting User Manual
