PARTS LIST
No.
Description
Spec.
Qty
No.
Description
Spec.
Qty
1 Main Frame 1 32 Big Washer Ф32*Ф8*2.0 6
2 Front Post 1 33 Shaft Sleeve
Φ32*3.5*24*Φ
19
8
3 Left Swing Tube 1 34 Wave Washer Ф19*Ф26*0.3 4
4 Right Swing Tube 1 35 Bushing
Φ31.8*Φ19.2*
75
2
5 Rotating Sleeve Tube 2 36 Left Foot Bar Cover 2
6 Left Foot Bar 1 37 Right Foot Bar Cover 2
7 Right Foot Bar 1 38 Screw ST4.2*20 19
8 Foot Tube Connect Patch 2 39 Screw ST3.5*16 4
9 Front Stabilizer 1 40 Bolt M8*50 2
10 Rear Main Frame 1 41 Connecting Shaft Ф16*32 2
11 Left Handlebar 1 42 Shaft Sleeve 4
12 Right Handlebar 1 43 Left Pedal 1
13 Middle Handlebar 1 44 Right Pedal 1
14 Foam Grip Ф24*Ф30*500 2 45 Bolt M8*60 2
15 End Cap for Handlebar 2 46 Washer Ф8*Ф16*1.5 17
16 Hand Pulse Sensor L=850mm 2 47 Cap 2
16a Hand Pulse Sensor Wire 1 48 Bolt Φ16*88 2
17 Plug Ф12.1 1 49 Washer φ24*φ12.5*2 2
18 Screw ST4.2*20 2 50 Nut M12 2
19 Spring Washer Ф8 16 51 Roller Cover 2
20 Bolt M8*30 2 52 Stopper 2
21 Clamp Cover 1 53 Screw M4*8 8
22 Cap Ф32 2 54 Bolt M8*20 4
23 Foam Grip Ф31*Ф41*920 2 55 Washer Ф8*Ф20*2.0 4
24 Bolt M8*43 4 56
Roller Connecting
Shaft
Ф15*61.5 2
25 Big Arc Washer Ф8*Ф20*2.0 8 57 Roller Spacing Ф22*2 4
26 Nut M8 13 58 Bearing 6202 4
27 Left Handlebar Cover-A 1 59 Pulley Ф70*Ф29*50 2
28 Left Handlebar Cover-B 1 60 Shaft Sleeve Ф23.5*20 8
29 Right Handlebar Cover-A 1 61 Plastic Bushing Ф32*21 8
30 Right Handlebar Cover-B 1 62
Connecting Rod
Small Bushing
Ф18*Ф8*10 4
31 Bolt M8*16 4 63 Cap Ф38 2
