66
KM-560 series are manufactured for industry use to sew textiles and other similar material.
In case of running the machine, users should observe the following things.
ⓐ Ahead of operating the machine, please read the manual and understand fully the details
on its operation.
ⓑ Don’t forget to put on the garment suited for the safe work.
ⓒ Keep your hands or a part of the body away from the running part of the machine like a
needle, hook, thread take-up spring and pulley etc.
ⓓ Don’t remove any kind of cover for safety while running the machine.
ⓔ Be sure to connect the earthed line.
ⓕ Before opening the electric box such as a control box, be sure to shut off the power
supply and make sure that the power switch should be put on “off.”
ⓖ When threading the needle or before checking after sewing, be sure to stop the machine.
ⓗ Don’t switch on the power supply with the foot on the pedal.
ⓘ Don’t run the machine when the cooling fan are not running. Be sure to clean the air
filter in the control box once a week.
ⓙ If possible, keep off from the strong electronic wave like a high frequency welding
machine.
1-4) Machine
Operation
Warning
Warning
ⓐ Safety Label: Suggestions while running the machine are stated.
ⓑ Thread take-up spring cover: the device to prevent the human body from touching the
thread take-up spring.
ⓒ Belt cover: the device to prevent hands, feet and clothing from getting jammed by the
belt.
ⓓ Finger guard: the device to prevent fingers from contacting the needle.
1-5) Safety Device
Warning
Always start the machine with safety covers in place since fingers
or hands could be injured or cut off by the belt. Turn off the power
switch during check-ups or adjustments.
ⓓ
ⓐ
ⓒ
ⓑ
