1) Sewing machine
1
Specification
2) Motor
① Servo motor controller
MODEL
SC55-1B
SC55-1B
SC55-3B
VOLT
1 Phase 110V
1 Phase 220V
3 Phase 220V
WATT
550W
550W
550W
HERTZ
50/60 Hz
50/60 Hz
50/60 Hz
Item
KM-560-7(Trimming type)
KM-560(Ordinary type)
Usage
Max speed
Max stitch length
Needle bar stroke
Presser foot height
Needle
Hook
Reverse sewing
Conveying device
Lubrication
Bed scale
Power
Heavy materials ∼ Ultra thin materials
3,000 SPM
8 mm
34.2 mm
Manual : 10.5 mm, Knee : 16 mm
DP×17 #22 (#14~#25)
Unision feeding (Needle, Feed dog, Upper feed presser foot)
Semi-automatic drop oiler
475 ×177mm
Vertical stroke of upper feed
presser foot and auxiliary
presser foot
2 ∼ 5.5mm
② Clutch motor
MODEL
HEC-1706(1 Phase)
HEC-1705(3 Phase)
VOLT
110/220V
220/380V
WATT
400W
400W
HERTZ
50/60 Hz
50/60 Hz
3) Peripheral automation devices (optional)
UsageModelOptional device
AUTO KNEE LIFTING
SYSTEM
PRODUCTION
COUNTER
MATERIAL EDGE
SENSOR
STANDING PEDAL
SCOUN-1
SEDG-1C
SEDG-2C
SPDL-1
SPDL-2
A counting device which indicates the completed quantity on the program unit panel, including added,
subtracted, corrected or remaining quantity along with other performance rates.
A device that senses the edge or thickness of the sewing material to stop the machine without manual
pedaling. Available in two types: SEDG-1B for edge sensing type and SEDG-2B for thickness sensing
type.
An essential device when one person is operating multiple sewing machines. Has different pedals for
acceleration, thread trimming, presser foot and ascending pedal. Types consist of SPDL-1 for fixed
speed and SPDL-2 for variable speed.
SPF-4
A solenoid operating structure where the presser foot gets lifted automatically with pedal reverse gear
stage 1 operation.
max. stroke: 46 mm
input voltage: DC 24V (DC 24 ~ 46V)
induction at 46 mm stroke: 10kg
2 horizontal rotations 2.5 times trimming hook
1 Phase 110/220V, 3 Phase 220V 1 Phase 110/220V, 3 Phase 220/380V
Reverse button & Reverse lever
2 horizontal rotations 2.5 times trimming hook
Reverse lever
