2-3
2-4) ASSEMBLY OF PERIPHERAL DEVICES
1) Assembling Upper Thread Stand
2) Assembling Operation Box
[Fig.2-4]
[Fig.2-5] [Fig.2-6]
Spool plate
thread holder
Operation box
support
CN6(Joint Board to I/O Board 40P)
CN6(Joint Board to I/O Board 34P)
