7-22
7-4-2) Basic Set-up
When the machine is turned on and operating system loads, press . This allows the set-up of basic design
changes. Set-up items are as follows:
① X_Scale: Reduces or enlarges the design along the X axis (left to right).
The default is 100% and the allowed range runs from 50% to 200%.
The default is 100% and the allowed range runs from 50% to 200%.
② Y_Scale: Reduces or enlarges the design along the Y axis (top to bottom).
[100%] [200%]
[100%] [200%]
[100%]
[0°] [90°]
[200%]
Designs can be enlarged in both the X and the Y directions.
The default is 0°and designs can be rotated from 0 to 359°in the increments of 1°.
③ Angle: Rotates the design in a set angle.
