7-17
■■
EXTERNAL OUTPUT: Outputting Design
Ex) Sending data to another SWF machine via SERIAL communication.
The following screen will appear after
all data has been read from the tape.
To store the data, move the cursor to
“YES”and press
Call the desired design and select
“4. EXTERNAL OUTPUT”
When the receiving machine presses
SET, the data will be transmitted with
the following screen.
DO YOU WANT TO SAVE ?
[YES] [NO]
EXTERNAL OUTPUT
==> DATA PENDING !
EXTERNAL OUTPUT
==> DATA SENDING !
The tape format is automatically detected as
shown above. Procedures for GNT4604 and
SERIAL are the same as for GNT2910.
1. SERIAL
2. PARALLEL
To Next Page
